RG-RAP2260(H)

Highlight Features
  • Build ultra-fast and high-density Wi-Fi with 5.95Gbps throughput.
  • Client connections over 500, higher practical performance as well.
  • Boost Internet speed with 5Gbps uplink for the future.
  • Easily install extra AP with Reyee Mesh technology.
  • Support standalone captive portal, easy to enable Wi-Fi authentication.
Add to Quote

Delivery & Return

Pellentesque habitant morbi tristique senectus et netus et malesuada fames ac turpis egestas. Vestibulum tortor quam, feugiat vitae, ultricies eget, tempor sit amet, ante. Donec eu libero sit amet quam egestas semper. Aenean ultricies mi vitae est. Mauris placerat eleifend leo.

Delivery & Return

Pellentesque habitant morbi tristique senectus et netus et malesuada fames ac turpis egestas. Vestibulum tortor quam, feugiat vitae, ultricies eget, tempor sit amet, ante. Donec eu libero sit amet quam egestas semper. Aenean ultricies mi vitae est. Mauris placerat eleifend leo.

Delivery & Return

Pellentesque habitant morbi tristique senectus et netus et malesuada fames ac turpis egestas. Vestibulum tortor quam, feugiat vitae, ultricies eget, tempor sit amet, ante. Donec eu libero sit amet quam egestas semper. Aenean ultricies mi vitae est. Mauris placerat eleifend leo.

Brands: Ruijie

Product Details

The Ruijie Reyee RG-RAP2260(H) WiFi 6 Access Point is an ideal choice for businesses looking to upgrade their wireless networks. It offers a high throughput of 5.95Gbps and supports over 500 client connections, making it perfect for environments that demand ultra-fast and reliable internet connectivity. The RG-RAP2260(H) also features a 5Gbps uplink, Reyee Mesh technology for easy network expansion, a standalone captive portal for simplified WiFi authentication, and centralised cloud network management. Its built-in omni-directional antenna ensures broad coverage, making it a versatile and efficient solution for modern business needs.

Device Type

Access Point, Ceiling Access Point

Product Type

Ceiling AP

Series

Wi-Fi 6 Ceiling AP

Wi-Fi Radio

Radio design: Dual-radio
Spatial streams: 8
2.4 GHz: 4 x 4, MU-MIMO
5 GHz: 4 x 4, MU-MIMO
Maximum wireless data rate: 5950 Mbps
6 GHz wireless data rate: No
5 GHz wireless data rate: 4803 Mbps
2.4 GHz wireless data rate: 1147 Mbps

Antenna

Antenna: 2.4 GHz: 4 built-in omnidirectional antennas; 5 GHz: 4 built-in omnidirectional antennas

Dimensions and Weight

Product dimensions (W x D x H): 230 mm x 230 mm x 49.5 mm (excluding the mounting bracket)
Color: White
Weight: ≤ 1.36 kg (without packaging materials)

Port Specifications

Number of 10/100/1000/2500BASE-T ports: 2

Power Supply and Consumption

Power supply: DC power adapter, PoE+/PoE++
Local power supply: Yes, one DC power connector (48 V, 1 A)
Dimensions of the DC connector: Outer diameter 5.5 mm, Inner diameter 2.1 mm, Depth 10 mm
PoE budget: No
Maximum power consumption: 40 W

Environment and Reliability

Operating temperature: 0°C to 40°C
Mounting options: Ceiling/Wall
IP rating: No

WLAN

Maximum number of associated wireless clients: 64 (2.4 GHz), 512 (5 GHz), 512 (2.4 GHz and 5 GHz enabled)
Maximum number of devices that can be managed: 300

IP Service

IPv6: Yes

Order Information

Access Point: 1
User Manual: 1
Certificate of Quality: 4
Screws and Wall Anchors: 1
Mounting Bracket: 1
Package Weight: 1.79 kg
Key to Security Lock: 1
