PBE-5AC-500

5 GHz WiFi antenna with a 450+ Mbps Real TCP/IP throughput rate.

  • 5 GHz, 25+ km link range
  • 450+ Mbps throughput
  • Improved mounting
  • Dedicated spectral analysis radio
  • Dedicated WiFi management radio

Note. This product should be purchased in pairs in order to form links

Add to Quote

Delivery & Return

Pellentesque habitant morbi tristique senectus et netus et malesuada fames ac turpis egestas. Vestibulum tortor quam, feugiat vitae, ultricies eget, tempor sit amet, ante. Donec eu libero sit amet quam egestas semper. Aenean ultricies mi vitae est. Mauris placerat eleifend leo.

Delivery & Return

Pellentesque habitant morbi tristique senectus et netus et malesuada fames ac turpis egestas. Vestibulum tortor quam, feugiat vitae, ultricies eget, tempor sit amet, ante. Donec eu libero sit amet quam egestas semper. Aenean ultricies mi vitae est. Mauris placerat eleifend leo.

Delivery & Return

Pellentesque habitant morbi tristique senectus et netus et malesuada fames ac turpis egestas. Vestibulum tortor quam, feugiat vitae, ultricies eget, tempor sit amet, ante. Donec eu libero sit amet quam egestas semper. Aenean ultricies mi vitae est. Mauris placerat eleifend leo.

Category: Tags: , , ,
Brands: Ubiquiti

Product Details

5 GHz WiFi antenna with a 450+ Mbps Real TCP/IP throughput rate and 25+ km link range.

The airMAX PowerBeam 5AC 500 stands as a testament to Ubiquiti Networks’ dedication to pushing the boundaries of wireless broadband technology. This device is specifically engineered to meet the demands of high-performance wireless networks, offering unparalleled connectivity for point-to-point (PtP) and point-to-multipoint (PtMP) configurations. Operating within the 5 GHz frequency band, the PowerBeam 5AC 500 utilizes Ubiquiti’s proprietary airMAX ac technology to achieve significant improvements in throughput and signal integrity over long distances.
This product should be purchased in pairs in order to form links.
The PowerBeam 5AC 500 is specifically designed to work in conjunction with other airMAX ac devices. This includes various models of Ubiquiti’s outdoor wireless access points, bridges, and customer premises equipment (CPE) that also utilize airMAX ac technology. It’s also important to consider, that while the PowerBeam 5AC 500 is optimized for the airMAX series, direct operational integration with the UniFi series, which is tailored for managed Wi-Fi networking within indoor and semi-outdoor environments and uses a different management system (UniFi Controller), is not its primary feature. The distinct operational frameworks and intended applications of the airMAX and UniFi series limit their direct interoperability.
Device Type

5 GHz, Antennas, Outdoor

Dimensions:

Without radome: 520 × 520 × 308 mm
With radome: 525 × 525 × 315 mm

Certifications:

FCC, IC, CE, RoHS

Weight:

Without radome: 2.35 kg
With radome: 3.2 kg

Enclosure material:

UV-stabilized plastic

NDAA compliant:

Yes

Networking interface

(1) GbE RJ45 port

Power method

Passive PoE 2-pair (4, 5+; 7, 8 return)

Power supply

24V, 0.5A gigabit PoE adapter (Included)

Supported voltage range

20-27V DC

Max. power consumption

8.5W

ESD/EMP protection

Air/contact: ± 24 kV

LEDs

(1) Power, (1) LAN, (4) WLAN

Signal strength LEDs

Software-adjustable to correspond to custom RSSI levels

Salt fog test

IEC 68-2-11 (ASTM B117)
Equivalent: MIL-STD-810 G method 509.5

Vibration test

IEC 68-2-6

Temperature shock test

IEC 68-2-14

UV test

IEC 68-2-5 at 40° C (104° F)
Equivalent: ETS 300 019-1-4

Wind-driven rain test

ETS 300 019-1-4
Equivalent: MIL-STD-810 G method 506.5

Ambient operating temperature

-40 to 70° C (-40 to 158° F)

Ambient operating humidity

5 to 95% noncondensing

Gain

27 dBi

Max. VSWR

1.5:1

Channel sizes

PtP Mode: 10/20/30/40/50/60/80 MHz
PtMP Mode: 10/20/30/40 MHz

Polarization

Dual linear

Operating Frequency (MHz)

Worldwide 5150 – 5875 MHz

USA
U-NII-1: 5150 – 5250 MHz
U-NII-2A: 5250 – 5350 MHz
U-NII-2C: 5470 – 5725 MHz
U-NII-3: 5725 – 5850 MHz
