The Ubiquiti UniFi UAP AC Lite access point delivers a cost-effective combination of value and performance in a reduced footprint, with an ultra compact design. The UAP-AC-Lite is 25% smaller than the standard UAP. It provides simultaneous, dual-band and 2×2 MIMO technology.
 |
||
 |
 |
 |
| Link | |
|---|---|
| Dimensions | 160 x 31.45 mm (6.3 x 1.2") |
| Weight | Without mount: 170 g (6 oz) With mount: 185 g (6.5 oz) |
| Networking interface | (1) GbE RJ45 port |
| Management interface | Ethernet |
| Power method | PoE Passive PoE, 24V (Pairs 4, 5+; 7, 8 return) |
| Power supply | UniFi PoE switch 24V, 0.5A Gigabit PoE adapter* |
| Max. power consumption | 6.5W |
| Max. TX power | 2.4 GHz: 20 dBm 5 GHz: 20 dBm 6 GHz: – |
| MIMO | 2.4 GHz: 2 x 2 5 GHz: 2 x 2 6 GHz: – |
| Throughput rate | 2.4 GHz: 300 Mbps 5 GHz: 867 Mbps 6 GHz: – |
| Antenna gain | 2.4 GHz: 3 dBi 5 GHz: 3 dBi 6 GHz: – |
| Button | Factory reset |
| Mounting | Wall, ceiling (Included) |
| Ambient operating temperature | -10 to 70° C (14 to 158° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| WiFi standards | 802.11 a/b/g/n/r/k/v/ac |
| Wireless security | WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) |
| BSSID | Up to 8 per radio |
| VLAN | 802.1Q |
| Advanced QoS | Per-user rate limiting |
| Guest traffic isolation | Supported |
| Power save | Supported |
| WMM | Voice, video, best effort, and background |
| Concurrent clients | 250+ |
| Supported Data Rates (Mbps) | 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b: 1, 2, 5.5, 11 Mbps 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n: 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40) 802.11ac: 6.5 Mbps to 867 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80) |
| Device Type | Ceiling, Wi-Fi 5 |
